THE BEST PERSPECTIVE FROM 70-25000 TM

Flat Top Cranes

For a fast and reliable crane with the technology to position even the heaviest load at the site with pinpoint precision, see our range of Krøll flat top cranes. This range is ideal for sites with height restrictions as well as in situations when available mobile cranes restrict the weight of the individual crane components, as the flat top crane's jib can be erected and dismantled piece by piece!

Krøll offers an extensive range of flat top cranes spanning 130 to 630tm which ensures that we can meet any lifting requirements.

Years of experience in a worldwide market ensures that all concerns are addressed in every design. For instance, wherever possible all cranes and components are designed to be packed into standard shipping containers, minimizing shipping costs. Likewise, speed and ease of erection are always taken into account.

All of our flat top cranes are built to the highest quality offering our full array of features.

Flat Top Cranes

Metric

Model	Type	Max. Reach	Tip Load	Max. Load	Max. free HUH	Mast type	View spec. sheet
K130F	Flat Top	60 m	1.25 t	6 t		M16	PDF »
K130F	Flat Top	60 m	1.25 t	8 t		M16	PDF »
K230F	Flat Top	60 m	2.3 t	10 t		M22	PDF »
K330F	Flat Top	75 m	3.2 t	18 t	69 m	M22	PDF »
K430F	Flat Top	75 m	3.6 t	24 t	82 m	M28	PDF »
K630F	Flat Top	80 m	5.0 t	24 t	80 m	M28	PDF »

Imperial

Model	Type	Max. Reach	Tip Load	Max. Load	Max. free HUH	Mast type	View spec. sheet
K130F	Flat Top	197 ft	2,755 lbs	13,227 lbs		M16	PDF »
K130F	Flat Top	197 ft	2,755 lbs	17,636 lbs		M16	PDF »
K230F	Flat Top	197 ft	5,071 lbs	22,046 lbs	220 ft	M22	PDF »
K330F	Flat Top	246 ft	7,055 lbs	39,683 lbs	226 ft	M22	PDF »
K430F	Flat Top	246 ft	7,937 lbs	52,910 lbs	269 ft	M28	PDF »
K630F	Flat Top	262 ft	11,023 lbs	52,911 lbs	262 ft	M28	PDF »

Next step Cockpit

Please contact us for futher information on flat top cranes

Krøll Cranes: For over half a century we have been designing and manufacturing quality tower cranes ranging from 70 to 25,000tm. No matter what size you need you are ensured the highest manufacturing and technology standards, a make-to-order solution and responsive, knowledgeable service.

Read more »

Krøll Cranes is a member of Muhibbah Enginering Group

KRØLL CRANES A/S - Nordkranvej 2 - DK-3540 Lynge - Tel: +45 48187400 - Fax: +45 48188807 - Email: info@krollcranes.dk

Custom made cranes for any application

Count on the highest manufacturing standards and knowledgeable service from the world leader in heavy duty tower cranes to help you get the job done in a profitable way.

High quality, low maintenance

Krøll's range of tower cranes offer versatile and reliable solutions for the most demanding lifting operations. Their ability to cover a large area on a small footprint make them ideal machines to meet the toughest lifting requirements on even the most challenging jobsite, to help ensure that you finish your job on time, every time.
