Hammerhead Cranes

For a fast and reliable crane with the technology to position even the heaviest load at the site with pinpoint precision, see our range of Krøll hammerhead cranes.

Spanning 160 to 25,000tm, Krøll offers an extensive range of models, indluding the biggest ever manufactured tower crane: the K10000. With our new range of flat-top cranes we are sure to meet any lifting requirement.

Years of experience in a worldwide market ensures that all concerns are addressed in every design. For instance, wherever possible all cranes and components are designed to be packed into standard shipping containers, minimizing shipping costs. Likewise, speed and ease of erection are always taken into account.

All of our hammerhead cranes are built to the highest quality offering our full array of features.

Hammerhead Cranes

Search word:

System

(select)ImperialMetric

Metric

Model	Type	Max. Reach	Tip Load	Max. Load	Max. free HUH	Mast type	View spec. sheet
K70	High Top	45 m	1.2 t	5 t	40 m	M12	PDF »
K180	High Top	60 m	2.3 t	10 t	54 m	M16	PDF »
K180	High Top	60 m	2.3 t	10 t	67 m	M22	PDF »
K320	High Top	75 m	3.2 t	18 t	69 m	M22	PDF »
K420	High Top	75 m	3.6 t	24 t	82 m	M28	PDF »
K560	High Top	81.6 m	4.2 t	24 t	90 m	M28	PDF »
K800	High Top	78 m	9.0 t	30 t	100 m	M40	PDF »
K1000	High Top	78 m	11.0 t	30 t	100 m	M40	PDF »
K1400	High Top	80 m	16.0 t	40 t	80 m	M40
K1800	High Top	80 m	14.0 t	60 t	80 m	M40/TM50
K2500	High Top	85 m	20.0 t	70 t	85 m	TM50
K3000	High Top	96 m	20.0 t	100 t	85 m	TM50/TM60
K4000	High Top	90 m	30.0 t	110 t	100 m	TM60
K5000	High Top	90 m	40.0 t	120 t	60 m	TM60
K10000	High Top	82 m	120.0 t	240 t	82 m	TM80	PDF »
K5000S	High Top	60 m	59.0 t	250 t	60 m	TM60	PDF »

Imperial

Model	Type	Max. Reach	Tip Load	Max. Load	Max. free HUH	Mast type	View spec. sheet
K70	High Top	148 ft	2,646 lbs	11,023 lbs	131 ft	M12
K180	High Top	197 ft	5,071 lbs	22,046 lbs	177 ft	M16
K180	High Top	197 ft	5,071 lbs	22,046 lbs	220 ft	M22	PDF »
K320	High Top	246 ft	7,055 lbs	39,683 lbs	226 ft	M22	PDF »
K420	High Top	246 ft	7,937 lbs	52,910 lbs	269 ft	M28	PDF »
K560	High Top	268 ft	9,259 lbs	52,910 lbs	295 ft	M28	PDF »
K800	High Top	256 ft	19,841 lbs	66,138 lbs	328 ft	M40	PDF »
K1000	High Top	256 ft	24,251 lbs	66,138 lbs	328 ft	M40
K1400	High Top	262 ft	35,274 lbs	88,184 lbs	262 ft	M40
K1800	High Top	262 ft	30,864 lbs	132,276 lbs	262 ft	M40/TM50
K2500	High Top	279 ft	44,092 lbs	154,322 lbs	279 ft	TM50
K3000	High Top	315 ft	44,092 lbs	220,460 lbs	279 ft	TM50/TM60
K4000	High Top	295 ft	66,138 lbs	242,506 lbs	328 ft	TM60
K5000	High Top	295 ft	88,184 lbs	264,552 lbs	197 ft	TM60
K10000	High Top	269 ft	264,552 lbs	529,104 lbs	269 ft	TM80	PDF »
K5000S	High Top	197 ft	130,071 lbs	551,150 lbs	197 ft	TM60	PDF »
